Excavators Cutting Edge 4T6566-M Motor Grader Blade CuttingEdge
I. Components
Core Parts:
Track Rollers (Support Rollers)
Idlers (Guide Wheels)
Sprockets (Drive Wheels)
Carrier Rollers (Upper Rollers)
Track Assembly (Track Chains, Links, Track Shoes)
Track Tensioning System (Tension Cylinder, Tension Spring)
Auxiliary Parts:
Track Links, Track Pads, Track Frames, Hitch Frames, Pins/Bushings
Swing Rings, Track Shoe Bolts/Nuts, Track Guards, Travel Motor Covers
Specialized Designs:
Lubricated Track Adjusters
Triple-Reinforced Shoes (e.g., 600mm/800mm width)
Tow Hooks, Track Covers (e.g., for ZX-7H 345USLC models)
II. Key Features
Critical Importance:
Undercarriage accounts for 25% of excavator manufacturing costs.
Directly impacts machine stability, mobility, and maintenance costs (often >50% of lifetime expenses).
Durability & Adaptability:
Reinforced track chains with sealed pins.
Wear-resistant rubber tracks and quarry-grade rollers for rocky/abrasive terrains.
Custom designs: Amphibious (swamp/marsh), remote-controlled (orchard use), or mountain/mud tracks.
Serviceability:
Detachable sprocket segments.
Direction-marked track frames for easy reassembly.
III. Common Models
Machine Compatibility:
Komatsu: PC60, PC100-5/6, PC130-7, PC160-7, PC300-7, PC400/420/450
Hitachi/Hyundai:EX55/60,ZX55/70/110/120/130/750/800;
Hyundai:R60/R80/R130/R210/R300/R330LC/R455
Other Brands: SANY SY55/SK210/SK250-8, XCMG XE215, Liugong 920E, Zoomlion ZE120/130/150
Caterpillar: CAT E307/E390 (compatible with 374/390 chain links)
Component-Specific Models:
Track Rollers: ZAX110/ZAX120 rollers, SANY 55 rollers, SD16/SD22 rollers.
Tension Systems: Komatsu PC400-7 tension cylinder assembly.
| Part No. | Description | Weight | Model Application |
| (kg) | |||
| 5D9553 | DBC Grader Blade 1828*152*16 13*5/8" | 29 | 12G,12H,14T,112T,120,120G,120H,130G,135H,140H,140G,12F,322B |
| 5D9554 | DBC Grader Blade 2133*152*16 15*5/8" | 34 | 12G,12H,120G,120H,130G,16T,140H,135H,143H,12F |
| 5D9558 | DBC Grader Blade 1828*203*19 13*5/8" | 50 | 12G,12H,14T,112T,120,120G,135H,140G,140,152X,143H,140H,163H, |
| 160K,140K,12F | |||
| 5D9559 | DBC Grader Blade 2133*203*19 15*5/8" | 59 | 12G,12H,120G,120H,16T,140G,140K,143H,140H,135H,12F |
| 5D9556 | DBC Grader Blade 1828*152*19 13*5/8" | 35.5 | 12G,12H,14T,112T,120,120G,120H,130G,135H,12F |
| 5D9557 | DBC Grader Blade 2133*152*19 15*5/8" | 42 | 12G,12H,120G,120H,130G,16T,12F |
| 5D9562 | DBC Grader Blade 1828*203*16 13*5/8" | 42 | 12G,12H,14T,112T,120,120G,120H,135H,140G,140,152X,12F,140H,143H, |
| 135H,12F | |||
| 5D9561 | DBC Grader Blade 2133*203*16 15*5/8" | 49 | 12G,12H,120G,120H,16T,140G,143H,140H,135H,163H,160H,12F |
| 4T2244 | DBC Grader Blade 1828*203*25 13*5/8" | 68 | 3304,3306,120G,12G,130G,140G |
| 4T2242 | DBC Grader Blade 2133*203*25 15*5/8" | 79 | 3304,3306,120G,12G,130G,140G |
| 7D1158 | DBC Grader Blade 2133*203*16 15*3/4" | 49 | 14G,14H,120M,160K,160M,163H,160H,14M,140K,12M,143H |
| 7D1576 | DBC Grader Blade 1828*203*19 13*3/4" | 50 | 12M,120K2,120K,120M,143H,12K,160M,163H,140M,140K,160H, |
| 7D1577 | DBC Grader Blade 2133*203*19 15*3/4" | 59 | 14G,14H,12M,143H,12K,140K2,14M,140M,163H,160M,140K,120M,120K |
| ,160H,160K,160HNA,120M2AWD,160M3,12M2,160M2AWD,12M2AWD, | |||
| 120K2,12M,140M2,120M2,160M2,143H,14LAWD,140M3,140K,140MAWD, | |||
| 14H,160MAWD,120MAWD,140HNA,160H,12HNA,12M3,14M3 | |||
| 4T2231 | DBC Grader Blade 1828*203*25 13*3/4" | 68 | 18M3,16H |
| 4T2233 | DBC Grader Blade 2133*203*25 15*3/4" | 79 | 3304,3306,3406,130G,14G,16G,12G,140G |
