grader blades and cutting edges Our main products are grader blades, cutting edges and bucket teeth. Grader blades are mainly applied on motor graders. For grader blades, we can provide C80 (carbon steel) and 30MnB (heat-treated boron steel). The hardness of carbon steel is HB280-320 and the hardn

Everything you should know about 5D9559Grader blades are used to create a flat surface or level during the leveling process, and knowing the size and material of the curved board is important for you to choose a blade for your grader Today we will introduce the 5D9559, which is suitable for CAT120,

5D9559, which is suitable for CAT 120, 120G, 120H, 120H ES, 120H NA, 12F, 12G, 12H, 12H ES, 12H NA, 130G, 135H, 135H NA, 140, 140B, 140G, 140H, 140H ES, 140H NA, 140K, 143H, 14E, 16, 160G machine CAT 5D9559-3/4X8X84" 5/8P GR.BLADE Measurement: Weight:59KG Width:203mm Thickness19mm Length:2133mm Bolt:5/8" plow bolt Bolt Qty.:15 Material: High carbon steel（C80）---If you are the customer who in the earthmoving industry,and need a favorable price，you can choose C80 Material Heat treated boron steel (30MnB)---If you are the customer who in the mining industry,and need a high quality，you can choose 30MnB Material

4T6381 EDGE-CUTTING Caterpillar parts990, 990 II, D10T, D8N, D8R, D8R II, D8T 4T6381 DBF Cutting Edge 1353*330*30 9*1" 97.7KG Description Part No.:4T6381 Description:DBF Cutting Edge Applied Machine:Dozer Measurement: Weight:97.7KG Width:330mm Thickness:30mm Length:1353mm Bolt:1" plow bolt Bolt Qty.:9

5D9553, which is suitable for CAT 120, 120B, 120G, 120H, 120H ES, 120H NA, 12E, 12F, 12G, 12H, 12H ES, 12H NA, 130G, 135H, 135H NA, 140, 140G, 140H, 140H ES, 140H NA, 143H, 14E, 322B machie CAT 5D9553 Ggrader Blade1828*152*16 13*5/8" 29kg Description Part No.:5D9553 Description:Curved grader blade Applied Machine:Motor grader Measurement: Weight:29KG Width:152mm Thickness:16mm Length:1828mm Bolt:5/8" plow bolt Bolt Qty.:13 Matched bolts &nuts： 3F-5108 + 4K-0367 : 5/8" UNC-11X2-1/4"+Nut Grader blade: we have two material: one is 30MnB(best quality), the other is C30( medium quality). The specifications of our profiles are: 152*13mm 152*16mm 152*19mm 203*16mm 203*19mm 203*25mm The length of grader blade we can produce: 1219mm(4ft) 1524mm(5(ft) 1828mm (ft) 2133mm(ft) 2438mm(ft)

Applicable Models:12E 9W2297 Ggrader Blade 1828*152*13 13*5/8" 24.5kg Description Part No.:9W2297 Description:Curved grader blade Applied Machine:Motor grader Measurement: Weight:24.5KG Width:152mm Thickness:13mm Length:1828mm Bolt:5/8" plow bolt Bolt Qty.:13 Matched bolts &nuts： 3F-5108 + 4K-0367 : 5/8" UNC-11X2-1/4"+Nut Offering OEM fit and finish, General Duty motor grader cutting edges deliver consistent performance in low impact and finish grading applications. They are manufactured from high-carbon steel, boron steel, making them a reliable and affordable cutting edge option for cost-focused customers. ​ General Duty motor grader cutting edges fit correctly on any brand of motor grader. Curved cutting edges are designed to penetrate the roadway better than flat edges while carrying existing material forward to leave a smooth even surface.

Caterpillar Style Bucket Tooth with pin & retainer 1U3302 /1U3302RC- J300 Buceket teeth:1U3302/1U3302RC weight: 1U3302:4kg 1U3302RC:5.4kg Adapter: 3G6304 7.2kg Pins&lock:9J2308 &8E6259 Service: 1. OEM Part Number or Customized 2. Color: yellow or as customer required 3. Logo: Yassian logo, No logo or customer logo 4. Make as per your dimension or drawings provided 5. Supply the correct Plow bolts and nuts for the bolt on teeth and adapter Popular Part No: 1U3302,1U3252,6Y3222, 1U3352,1u3352RC, 9W8452/1U3452, 6I6602, 9W8552, 9W8552RC, 7T3402, 7T3402RC, 4T5501, 4T5502, 6Y3552, 6Y0309, 6Y0359, 9W2451, 9W2452,2713-1217, 2713-1219, E161-3027, E262-3046, 3G8304, 3G8354, 1U1357, 6I6354 , 6I6404,8E0464, 6I6464, 1U1304,114-0464, 53103205, 53103208, 53103209,333/D8455, 333/D8456, 333/D8457...

Today we will introduce the 5D9554, which is suitable for CAT 120, 120G, 120H, 120H ES, 120H NA, 12E, 12F, 12G, 12H, 12H ES, 12H NA, 130G, 135H, 135H NA, 140, 140G, 140H, 140H ES, 140H NA, 143H, 14E, 160G machie 5D9554 Grader Blade 2133*152*16 15*5/8" 34kg Description Part No.:5D9554 Description:Curved grader blade Applied Machine:Motor grader Measurement: Weight:34KG Width:152mm Thickness:16mm Length:2133mm Bolt:5/8" plow bolt Bolt Qty.:15 Matched bolts &nuts： 3F-5108 + 4K-0367 : 5/8" UNC-11X2-1/4"+Nut Sort Name Motor grader blades Service OEM Part Number or Customer Design Logo: No logo or customer's logo Color: yellow or as customer required Plow bolts and nuts are available

Buceket teeth: 1U3452/1U3452RC G. E. T Excavator Parts Bucket Tooth Bolt on Adaptor Tip Casting weight: 1U3452:12kg 1U3452RC:13.5KG Adapter: 6I6464 18.8kg Pins&lock:8E8468 &8E8469 Popular Part No: 1U3302,1U3252,6Y3222, 1U3352,1u3352RC, 9W8452/1U3452, 6I6602, 9W8552, 9W8552RC, 7T3402, 7T3402RC, 4T5501, 4T5502, 6Y3552, 6Y0309, 6Y0359, 9W2451, 9W2452,2713-1217, 2713-1219, E161-3027, E262-3046, 3G8304, 3G8354, 1U1357, 6I6354 , 6I6404,8E0464, 6I6464, 1U1304,114-0464, 53103205, 53103208, 53103209,333/D8455, 333/D8456, 333/D8457...

Buceket teeth: 1U3202RC/1U3202 Bucket Teeth Caterpillar J200 weight: 1U3202:1.2kg 1U3202RC:1.3KG Adapter: 8J7525: 18.8kg Pins&lock:8E8408 &8E8409 Home / Caterpillar Style / Caterpillar Style Bucket Teeth / 1U3202RC Bucket Teeth Caterpillar J200 1U3202RC Bucket Teeth Caterpillar J200 Specification: Part No.1U3202RC/1U-3202RC Weight 1.3-1.6 KG Brand Name: OEM AVAIABLE Replacement Brand: Caterpillar/ CAT Material High spec alloy steel Color：Yellow, black, red, green or as your required Process Investment： casting / Lost wax casting / sand casting / forged / forging Packing ： Normal plywood case about 2tons per case Tensile Strength ≥1400Rm-N/mm2 Shock ≥20J Hardness： 48-52HRC Certification： ISO9001:2008 Samples Offer sample with free of charge, but freight collect. Place of Origin Zhejiang, China(Mainland)
