What are the special parts of the Volvo EC500 Electric excavator
As a pure Electric large excavator, the Volvo EC500 Electric's special accessories are mainly designed around the electric drive system and dedicated structural components, as follows:
⚡️ electric system core components
250kW electric unit : It can replace traditional diesel engines and provide continuous power output. It requires high-voltage cables and a cooling system .
Lithium battery thermal management system : It includes a dedicated heat sink, temperature sensor and battery management computer board to ensure the stable operation of the battery pack in an environment ranging from -25°C to 50°C .
High-voltage relay groups (such as model 20797920) : used for controlling the on-off of circuits, with a protection grade of IP67, suitable for the humid environment of mines .
special structural parts and vulnerable parts
Reinforced small arm cylinder (cylinder diameter 140mm) : compatible with the 230kN pressurized digging force of the electric version, the chrome plating layer of the piston rod is thickened to prevent corrosion .
Three-toothed track plate (600mm wide) : chain link spacing 216mm, with a fully protective bottom cover to reduce wear caused by stones getting stuck in .
Electric special counterweight block (10,300kg) : the center of gravity distribution is optimized for the battery pack position, and the tail turning radius is only 3,880mm .
Electronic control and hydraulic special accessories
B series pilot filter assembly (model 0332) : filtration accuracy 10μm, protecting the electric hydraulic pump from contamination .
Multi-mode control computer board : supports dual mining mode switching of "normal/pressurized", and real-time monitoring of energy consumption data .
Low-noise hydraulic pump set : working noise ≤71dB, matched with the stepless speed regulation characteristic of the motor .
Note: : Some accessories (such as radiator water pipes 22140179) require power-specific versions and are not compatible with traditional diesel models .
