Reasons for the selection of materials for making bucket teeth
In construction machinery, the material selection of bucket teeth directly affects their wear resistance, impact resistance and service life, and a comprehensive decision should be made in combination with the characteristics of the working conditions.
I. Core Material Types and Their Applicable Scenarios
High manganese steel (such as ZGMn13 series)
Characteristics : The initial hardness is relatively low (HB200), but under impact load, the surface rapidly hardens to above HB500, forming a "self-reinforcing armor" effect. The austenitic structure endows it with extremely high toughness and strong crack resistance.
Applicable scenarios : medium and low impact earthwork operations, sand and gravel excavation, etc. It has a high cost performance, but the welding repair requires special welding rods and preheating processes.
Forging alloy steel (such as 40CrMnMo)
Characteristics : The closed die forging process achieves a density of 7.8g/cm³, with significant grain refinement. The surface hardness is HRC52-55, the core maintains HRC38-42 toughness, and the fatigue life is twice that of castings.
Applicable scenarios : rock mining in mines, high-intensity impact conditions (such as iron ore, basalt). Representative product: Caterpillar D11 mining bucket teeth.
Casting low alloy steel
Composition examples : C 0.38%, Cr 0.91%, Mn 0.83%, Si 0.92%. Heat treatment is required to optimize the uniformity of the microstructure.
Limitation : Casting porosity/sand hole defects lead to a decline in mechanical properties. It is only recommended for ordinary earthwork operations.
Ii. Core Basis for material Selection
Wear resistance priority
Rock conditions : Forged alloy steel must be selected, with tungsten carbide coating (HV≥1200) for further anti-peeling.
Wear-dominated scenario : high manganese steel relies on the work-hardened layer to resist abrasive wear.
Shock resistance requirements
The forged part is formed by three-way compressive stress and can withstand a digging force of ≥20 tons (the transverse gear pin structure is more reliable).
Under severe impact, the hardened layer thickness of high manganese steel can reach 5-10mm, avoiding brittle fracture.
Corrosive environment fit
Nickel/chromium alloy steels (such as Cr-Ni-Mo series) resist acidic soil or salt spray corrosion, extending their service life by more than 30%.
Cost-efficiency balance
Casting low alloy steel has the lowest cost, but its service life is only 50% of that of forged parts, making it suitable for short-term projects.
The unit price of forgings is 1.5 times that of castings, but their lifespan is doubled, making them more economical for long-term use.
Iii. Correlation between Process and Performance
Process: tensile strength: defect rate: applicable material:
Closed die forging ≥980 MPa porosity ≤0.1% alloy structural steel
Cast + water toughening treatment 650-800 MPa, sand holes ≥3% high manganese steel/low alloy steel
Operation prompt : When replacing the bucket teeth, the model of the tooth seat should be matched (the vertical installation type is easy to disassemble but has weak load-bearing capacity, while the horizontal installation type has stronger anti-digging force). The mine suggests checking the wear of the tooth tips every shift and replacing them in time to avoid damaging the tooth base.
