Advantages of hub mixer trucks
With the innovative technology of axial flux motor, the hub mixer truck has achieved breakthrough advantages in multiple dimensions, which are specifically manifested as follows:
⚙️ 1. Extreme lightweight and structural stability
Ultra-light drive system
The total weight of the hub "axial flux motor + reducer" is only 34kg, which is over 50% lighter than the traditional radial flux motor solution (over 80kg), greatly reducing the stress load on the stirring tank and avoiding the risk of shell damage or bolt breakage .
CAE analysis and verification show that when the total drive weight exceeds 45kg, the structure of the reducer needs to be strengthened, while the 34kg design makes the connection more stable and reliable .
2. Compact space adaptability
Revolutionary reduction in axial dimension
The overall axial dimension of the drive system is only 225mm, which is more than 50% shorter than that of the radial flux motor of the same power, perfectly adapting to the narrow space between the battery compartment and the driver's cabin of the mixer truck .
The convenience of installation and maintenance has been enhanced
The compact design frees up more working space and significantly improves maintenance convenience, especially suitable for the "backpack" type electric mixer truck layout .
⚡️ III. High efficiency, energy saving and long service life
"Double 90" energy efficiency performance
Axial flux motors can achieve a working efficiency of over 90% under 90% or more operating conditions , with a wide high-efficiency range coverage, effectively reducing the vehicle's energy consumption and increasing the driving range .
Heat dissipation and reliability upgrade
The heat dissipation performance is enhanced by 4 times . The unique electromagnetic structure avoids the risk of electrical corrosion of the bearing, and the long-term operation stability is stronger .
IV. Multi-scenario Compatibility and Expansion value
Full energy type compatible
Compatible with various new energy vehicle models such as pure electric, hybrid, hydrogen fuel and range-extended, and can also transform traditional fuel vehicles to achieve "electrification of the upper body" .
Integrated value-added solution
Customized electric drive axles (such as "axial motor + three-speed transmission") are provided, reducing energy consumption by more than 15% . The chassis space is optimized by placing the power battery at the bottom, lowering the center of gravity by 130mm and enhancing the anti-roll capability by .
market validation and global application
Domestically, it covers mainstream brands such as Foton, Sany and XCMG, and overseas, it has expanded to Southeast Asia, Europe and America. It has delivered over 4,000 units cumulatively, and its market share is expected to reach 30% in the first half of 2025.
Terminal feedback confirmed its low failure rate and maintenance cost advantage, supporting the electrification penetration rate of mixer trucks to exceed 60% (predicted for 2025) .
Summary: The hub technology redefines the driving standards of mixer trucks with its lightweight structure , ultra-compact size and high-efficiency energy-saving features , providing reliable underlying support for new energy construction machinery.
